Alpha ESS C&I Energy Storage Systems

With capacities ranging from 30kW to 30+mW, Alpha ESS offers an extensive selection of commercial and industrial energy storage solutions. Some of its key characteristics include LFP battery technology, exceptional thermal safety, high energy density, and high charge/discharge efficiency.

LFP Batteries
High Charge/Discharge (1P or 1C)
High Energy Density
High-Power Cooling Solution

Enquire Now

Alpha-CS

250 / 500 kW | Expandable to MWhs | Outdoor

The Alpha-CS 250/500 kW battery system is a strong and adaptable energy storage system that may be utilised for various applications. It is the perfect option for companies and organisations who want to save the most energy possible because it can load shift, peak shaving, and manage demand costs. The Alpha-CS 250/500 kW battery system can give you the peace of mind knowing that it has a 24/7 feature.

Load shifting
Off-grid ability
Peak shaving
Backup function
Demand charge management
24/7 monitoring
3-year product warranty, 10-year performance warranty

System Specification


Nominal Output Power	500 kW	250 kW
Max. AC Power	550 kW
Battery Chemistry	LFP（LiFePO4)	LFP（LiFePO4)
Application Environment	Outdoor (Container)	Outdoor (Container)
Warranty	3 Year Product Warranty, 10 Year Performance Warranty	3 Year Product Warranty, 10 Year Performance Warranty

Datasheet

Battery Specification


Module Model	M48240-S	M38210-S	M48112-S
Nominal Voltage	48 V	38.4 V	51.2 V
Module Capacity	11.5 kWh	8.1 kWh	5.7 kWh
Max. Charging/Discharging Rate	5.75 kW (0.5P)	4.05 kW (0.5P)	5.7 kW (1P)
IP Protection	IP20	IP20	IP20
Cycle Life	≥ 6000	≥ 6000	≥ 6000
Operating Temperature Range	-10 °C ~ 50 °C	-10 °C ~ 50 °C	-10 °C ~ 50 °C
	DATASHEET	DATASHEET	DATASHEET

Enquire Now

STORION-T50/100

50 / 100 kW | 34.4 - 2073.6 kWh

The STORION-T50/100 is one of the most powerful battery systems available in the market. It has a double inverter capacity PV input that can be used for off-grid applications. Thanks to its modular design, the system may be easily expanded or contracted as needed. And with its STS integrated transformer module, it is even more adaptable. It is also one of the easiest to set up and use.

System Specification


Nominal Output Power	100 kW	50 kW
Max. PV Input Power	200 kW	100 kW
Capacity Range	34.4 ~ 2073.6 kWh (90% DoD)	34.4 ~ 2073.6 kWh (90% DoD)
Battery Chemistry	LFP（LiFePO4)	LFP（LiFePO4)
Application Environment	Indoor (Rack) / Outdoor (Container)	Indoor (Rack) / Outdoor (Container)
Warranty	3 Year Product Warranty, 10 Year Performance Warranty	3 Year Product Warranty, 10 Year Performance Warranty

Datasheet

Battery Specification


Module Model	M38210-S	M48112-S
Nominal Voltage	38.4 V	51.2 V
Module Capacity	8.1 kWh	5.7 kWh
Max. Charging/Discharging Rate	4.05 kW (0.5P)	5.7 kW (1P)
IP Protection	IP20	IP20
Cycle Life	≥ 6000	≥ 6000
Operating Temperature Range	-10 °C ~ 50 °C	-10 °C ~ 50 °C
	DATASHEET	DATASHEET

Enquire Now

STORION-H30

30 kW | Max. 96.7 kWh

The STORION-H30 is a 30kW battery system hybrid-coupled system for on- and off-grid industrial applications. Its main features include:

Safety and reliability
High integration
Advanced air cooling technology
Multiple options charging/discharging rate: 0.25p~1p
Multiple operation modes automatic on/off grid switch within 30ms
Easy battery installation - plug and play without cable connection
High flexibility support parallel connect on DC/AC side

System Specification


Nominal Output Power	30 kW
Maximum storage capacity	96.7 kWh
Battery Chemistry	LFP (LiFePO4)
Parallel connection	Max. 10 on DC side & Max. 3 on AC side
IP Protection	IP54 (Outdoor)
Dimension (W x D x H)	1200x900x2160mm

Datasheet

Battery Specification


Module Model	M38210-S	M7790-S
Nominal Voltage	38.4 V	76.8 V
Module Capacity	8.1 kWh	6.93 kWh
Max. Charging/Discharging Rate	4.05 kW (0.5P)	6.93 kW (1P)
IP Protection	IP20	IP20
Cycle Life	≥ 6000	≥ 6000
Operating Temperature Range	-30 °C ~ 50 °C	-30 °C ~ 50 °C
	DATASHEET

Enquire Now

STORION-T30

30 kW | 28.7 ~ 68.8 kWh

The STORION-T30 is a 30kW hybrid-coupled system for on- and off-grid industrial applications. Its main features include:

different charging/discharging rates to ensure a fast and secure adaptation to changing loads and requirements.
highly flexible support panel that offers an extra layer of defence against power interruptions and voltage swings.
cutting-edge air conditioning technology for an effective and dependable operation amidst harsh environments
plug-and-play design so you can install and commission it quickly and efficiently without any downtime

Other features also include:

Flexible power modular design
24/7 monitoring with local interface
AC-coupled solution
Optional STS module
Transformer integrated
Multiple options
3-year product warranty, 10-year performance warranty

System Specification


Nominal Output Power	30 kW
Max. AC Input Power	30 kW
Capacity Range	28.7 ~ 68.8 kWh
Battery Chemistry	LFP（LiFePO4)
IP Protection	IP21
Warranty	3 Year Product Warranty, 10 Year Performance Warranty

Datasheet

Battery Specification


Module Model	M48112-S
Nominal Voltage	51.2 V
Module Capacity	5.7 kWh
Max. Charging/Discharging Rate	5.7 kW (1P)
IP Protection	IP20
Cycle Life	≥ 6000
Operating Temperature Range	-10 °C ~ 50 °C
	DATASHEET

Enquire Now

STORION-TB250/500

30 kW | 28.7 ~ 68.8 kWh

The STORION-TB250/500 battery system features a 250/500 kW system that can be expanded to MWhs as needed. Given its heavy-duty capacity, the STORION-TB250/500 battery system can supply power to industrial facilities. Included in the system’s main components are an AC-coupled solution and a maximum 10 x 50 kW PV string inverter.

Heavy-duty industrial application
AC-coupled solution
With max.10 x 50 kW PV string inverter
250 kW transformer integrated
500 kW transformerless

System Specification


Nominal Output Power	500 kW	250 kW
Max. AC Power	550 kW	275 kW
Capacity Range	Expandable to MWhs	Expandable to MWhs
Battery Chemistry	LFP（LiFePO4)	LFP（LiFePO4)
Application Environment	Indoor	Indoor
Warranty	3 Year Product Warranty, 10 Year Performance Warranty	3 Year Product Warranty, 10 Year Performance Warranty

Datasheet

Battery Specification


Module Model	M38210-S	M48112-S
Nominal Voltage	38.4 V	51.2 V
Module Capacity	8.1 kWh	5.7 kWh
Max. Charging/Discharging Rate	4.05 kW (0.5P)	5.7 kW (1P)
IP Protection	IP20	IP20
Cycle Life	≥ 6000	≥ 6000
Operating Temperature Range	-10 °C ~ 50 °C	-10 °C ~ 50 °C
	DATASHEET	DATASHEET
